MSI B650M Gaming WIFI DDR5 Motherboard

Brand: MSI

EGP 8,200.00 EGP 9,666.00

  • Brand: MSI
  • Model: B650M Gaming WIFI DDR5
  • Socket: AMD AM5 – Supports Ryzen™ 7000 Series CPUs
  • Memory: DDR5 support for high-speed and high-capacity RAM
  • Expansion: PCIe 4.0 ready for next-gen GPUs and storage
  • Storage: Dual M.2 Gen4 slots for ultra-fast NVMe SSDs
  • Networking: Wi-Fi 6E for low-latency, high-speed wireless
  • 2.5Gb Ethernet LAN for fast wired connectivity
  • Bluetooth 5.3 for seamless peripheral pairing
  • Audio: Audio Boost for premium sound clarity
  • Form Factor: Micro-ATX – perfect for compact gaming rigs
  • Cooling: Optimized for overclocking with reliable power delivery and heatsinks
(Available)
Quantity

SKU: B650M Gaming WIFI

Categories: Build Your PC, Motherboard

Tags: Motherboards, ماذربورد, MSI B650M Gaming WIFI

MSI B650M Gaming WIFI DDR5 Motherboard - Description



MSI B650M GAMING WiFi DDR5


Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors

Supports DDR5 Memory, up to 7800+(OC) MHz

Core Boost : With premium layout and digital power design to support more cores and provide better performance

Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility

MSI B650M GAMING WiFi


Lightning Fast Game experience: PCIe 4.0 slot, Lightning Gen4 M.2

Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability and strength

AUDIO BOOST: Reward your ears with studio grade sound quality for the most immersive gaming experience

High Quality PCB: 6-layer PCB made by 2oz thickened copper

See More PC Components

MSI B650M Gaming WIFI DDR5 Motherboard - Technical Specifications

BrandMSI
ModelB650M Gaming WIFI
ChipsetAMD B650
CPUSupports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors
Socket AM5
Memory

2x DDR5, Maximum Memory Capacity 128GB
Memory Support DDR5 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
• 1DPC 1R Max speed up to 7800+ MHz
• 1DPC 2R Max speed up to 6400+ MHz

Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports AMD EXPO™

Onboard Graphics1x HDMI™
Support HDMI™ 2.1, maximum resolution of 4K 60Hz

1x DisplayPort
Support DP 1.4, maximum resolution of 4K 60Hz
Slot1x PCI-E x16 slot
Supports x16/x1
• Supports x16/x4 (For Ryzen™ 9000/ 7000 Series processors)
• Supports x8/x4 (For Ryzen™ 8700/ 8600/ 8400 Series processors)
• Supports x4/x4 (For Ryzen™ 8500/ 8300 Series processors)
1x PCI-E x1 slot
PCI_E1 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E2 Gen PCIe 4.0 supports up to x16 (From CPU)
AudioRealtek® ALC897 Codec
7.1-Channel High Definition Audio
Storage2x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280 devices
M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280 devices
4x SATA 6G
RAIDSupports RAID 0, RAID 1, and RAID 10 for SATA storage devices
Supports RAID 0, RAID 1, and RAID 10 for M.2 NVMe storage devices
USB2x USB 2.0 (Rear)
4x USB 2.0 (Front)
3x USB 5Gbps Type A (Rear)
1x USB 5Gbps Type C (Rear)
4x USB 5Gbps Type A (Front)
Wireless LAN & BluetoothWi-Fi 6E
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX
Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands
Supports 802.11 a/ b/ g/ n/ ac/ ax
LANRealtek® RTL8125BG 2.5Gbps LAN
Internal IO1x Power Connector(ATX_PWR)
1x Power Connector(CPU_PWR)
1x CPU Fan
3x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
2x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
4x USB 5Gbps Type A ports
LED FEATURE4x EZ Debug LED
Operating SystemSupport for Windows® 11 64-bit, Windows® 10 64-bit
